JC-20T-04-8R1W
Round Dynamic Speaker
- Dimensions
- Ø20 × H3.4 mm
- Impedance
- 8 Ω ±15%
- Rated Power
- 1.0 W
PRODUCT SERIES
Speakers
Browse miniature speaker drivers by product shape and enclosure structure.
Find by model or specification
Filter by dimensions, impedance, power, structure or connection type.
36 products
No matching model found.
Send your installation space, driver conditions or target specifications.
Send requirements ↗
JC-SPKD36-MF01-16R1W
Round Dynamic Speaker
- Dimensions
- Ø36×5.0 mm
- Impedance
- 16Ω ±15%
- Rated Power
- Rated 1.0W / Max 2.0W
JC-SPK4020-MF01-8R1W-WL
Rectangular Dynamic Speaker
- Dimensions
- 40.0×20.0×5.8t
- Impedance
- 8Ω ±15%
- Rated Power
- 1.0W
JC-SPK4020-MF02-8R1P5W-WL
Rectangular Dynamic Speaker
- Dimensions
- 40.0×20.0×8.0t
- Impedance
- 8Ω ±15%
- Rated Power
- Rated 1.5W / Max 3.0W
JC-SPK3516-PF01-8R1W
Rectangular Dynamic Speaker
- Dimensions
- 35×16×5.8mm
- Impedance
- 8Ω ±15%
- Rated Power
- 1.0W
JC-SPK1813-PF01-8R1W-PN
Rectangular Dynamic Speaker
- Dimensions
- 18×13×4.5mm
- Impedance
- 8Ω ±15%
JC-SPK1511-MF02-8R0P7W-SC
Spring-Contact Miniature Speaker
- Dimensions
- 11×15×3.0t
- Impedance
- 8Ω ±15%
- Rated Power
- 0.7W
JC-SPK3411-PF01-4R1P5W
Rectangular Dynamic Speaker
- Dimensions
- 11×34×3.8±0.2 mm
- Impedance
- 4.2Ω ±20%
- Rated Power
- 1.5 W
JC-SPK1511-MF03-8R1W
Solder-Pad Miniature Speaker
- Dimensions
- 11×15×3.0 mm
- Impedance
- 8±15% Ω @ 2.0kHz / 2.83Vrms
- Rated Power
- 1W
JC-SPK1713-BOX01-8R1W-WL
BOX Speaker
- Dimensions
- 13×17×8.2 mm
- Impedance
- 8Ω ±15%
- Rated Power
- Rated 1.0W / Max 1.3W
JC-SPK1813-BOX01-8R1W-W
BOX Speaker
- Dimensions
- 18×13×5.0mm
- Impedance
- 8.0Ω ±20%
- Rated Power
- 1.0W
JC-SPKD15-BOX01-8R1W-PIN
Pin-Type Miniature Speaker
- Dimensions
- Ø15×H7.5 mm
- Impedance
- 8Ω ±15%
- Rated Power
- 1.0W
JC-SPKD23-BOX01-8R0P5W-PIN
Round BOX Pin-Terminal Dynamic Speaker
- Dimensions
- Φ23 × 6.8H mm
- Impedance
- 8 ±15% Ω
- Rated Power
- 0.5 W
JC-SPK2415-BOX01-8R1W-W
Rectangular BOX Speaker
- Dimensions
- 24×15×6.0mm
- Impedance
- 8.0Ω ±20%
- Rated Power
- 1.0W
JC-SPK2415-BOX02-8R1W-W
Racetrack BOX Speaker
- Dimensions
- 24×15×6.0mm
- Impedance
- 8.0Ω ±20%
- Rated Power
- 1.0W
JC-SPKD26-BOX03-8R0P5W-WL
BOX Speaker
- Dimensions
- Φ26×9.0 mm
- Impedance
- 8Ω ±15%
- Rated Power
- Rated 0.5W / Max 1.0W
JC-SPK2828-BOX01-4R2W-W
BOX Speaker
- Dimensions
- 28×28×10.0mm
- Impedance
- 4.0Ω ±20%
- Rated Power
- 2.0W
JC-SPKD30-BOX01-8R1W-PIN
Round BOX Pin-Terminal Dynamic Speaker
- Dimensions
- Φ30 × 12H mm
- Impedance
- 8 ±15% Ω
- Rated Power
- 1.0 W
JC-SPK3070-BOX01-8R2W-W
BOX Speaker
- Dimensions
- 31×70×16.5mm
- Impedance
- 8.0Ω ±20%
- Rated Power
- 2.0W
JC-SPK3080-BOX01-8R2W-W
BOX Speaker
- Dimensions
- 30.5×80mm
- Impedance
- 8.0Ω ±20%
- Rated Power
- 2.0W
JC-SPKD30-BOX01-8R1W-W
Enclosed Speaker
- Dimensions
- Φ30×13 mm (body); mounting width 35±0.3 mm
- Impedance
- 8±15%Ω / 2kHz / 1V
- Rated Power
- 1.0W
JC-SPKD30-BOX02-8R1W-W
Enclosed Speaker
- Dimensions
- Φ30×10.8±0.2 mm; Wire Length: 325±10 mm; 4P-1.25 Connector
- Impedance
- 8±15%Ω / 2kHz / 1V
- Rated Power
- 1.0W
JC-SPK3211-BOX01-8R1W-W
BOX Speaker
- Dimensions
- 32×11×5.4mm
- Impedance
- 8.0Ω ±20%
- Rated Power
- 1.0W
JC-SPK3370-BOX01-8R2W-W
BOX Speaker
- Dimensions
- 33×70×15.5mm
- Impedance
- 8.0Ω ±20%
- Rated Power
- 2.0W
JC-SPK3516-BOX01-4R1.5W-W
BOX Speaker
- Dimensions
- 35×16×6.5mm
- Impedance
- 4.0Ω ±20%
- Rated Power
- 1.5W
JC-SPK3520-BOX01-8R1W-W
BOX Speaker
- Dimensions
- 35×20×3.7mm
- Impedance
- 8.0Ω ±20%
- Rated Power
- 1.0W
JC-SPK3525-BOX01-4R3W-W
BOX Speaker
- Dimensions
- 35×25×6.3mm
- Impedance
- 4.0Ω ±20%
- Rated Power
- 3.0W
JC-SPK3718-BOX01-8R2W-W
BOX Speaker
- Dimensions
- 37×18×9.0mm
- Impedance
- 8.0Ω ±20%
- Rated Power
- 2.0W
JC-SPK4014-BOX01-8R2W-W
Round BOX Speaker
- Dimensions
- 40×14mm
- Impedance
- 8.0Ω ±20%
- Rated Power
- 2.0W
JC-SPK4016-BOX01-4R2W-WL
BOX Speaker
- Dimensions
- 40×16×8.0 mm
- Impedance
- 4Ω ±20%
- Rated Power
- Rated 2.0W / Max 3.0W
